Hardware Upgrades
1. Shut down the operating system properly, then turn off the
computer and any external devices, then disconnect the power
cord from the power outlet.
2. Remove the access panel and locate the memory module sockets.
WARNING: To reduce risk of personal injury from hot surfaces, allow
the internal system components to cool before touching.
3. Open both latches of the memory module socket 1 , and insert
the memory module into the socket 2 .
Begin by installing a module into the socket nearest the preinstalled
module, and install the modules following the numerical order of the
sockets.
A memory module can be installed in only one way. Match the notch
on the module with the tab on the memory socket. Push the module
down into the socket, ensuring that the module is fully inserted and
properly seated.
4. Close both latches of the memory module socket 3 .
2-6 Compaq Evo D300 User’s Guide
