C A R I N G F O R Y O U R R A N G E
Removing the broiler carriage
The broiler carriage can be removed for
lighting standing pilot oven burner and for
easier cleaning.
To remove:
1. Pull broiler drawer open. Broiler door will
tilt down when opened.
2. Remove
the broiler pan and grid.
Broiler pan
and grid
3. Slightly lift
broiler carriage and
pull
all
the way out.
Broiler
carriage
To replace:
1. Push
broiler carriage in until carriage is
locked UTKler placement tab in rear of
broiler carriage body.
Make sure
spring
clip at front of carriage snaps into slot
in
broiler carriage body.
Carriage must be
snapped into body whenever you are
baking.
2. Replace
broiler pan and grid.
3. Close
broiler drawer all the way.
21
