CARING FOR YOUR REFRIGERATOR
ClfANINC YOUR REFRIGERATOR
(
cokt
.)
PART
WHAT TO USE
HOW TO CLEAN
Defrost pan
Sponge or cloth with mild
• Remove base grille. (See below.)
detergent and warm water
• Reach into small opening at left edge and remove
the defrost pan.
• Wash, rinse, and dry thoroughly.
• Replace defrost pan. Make sure to push it com
pletely into the opening.
• Replace base grille.
Condenser
Vacuum cleaner with
• Remove base grille.
coils
extended narrow
• Vacuum coils when dusty or dirty. Coils may need
attachment
to be cleaned as often as every other month.
• Replace base grille.
R
emoving
THE BASE CRiuE
The base grille can be easily removed for access to
the defrost pan and condenser coils. You will need
to remove the base grille to clean the defrost pan or
the condenser colls (see above).
To remove the base grille:
1. Open both doors.
2.
Place hands along the ends of the grille, with
your thumbs along the top. Push in with your
thumbs and pull up on the bottom.
NOTE: Do not remove the Tech Sheet that Is
fastened behind the grille.
To replace the grille:
1. Line up the grille support tabs with the metal clips.
2.
Push the grille firmly to snap it into place and close
the doors.
Metal
clips
Base
grille
Support tabs
25
