CAMCORP, INC.
Phone: 913-831-0740 Fax: 913-831-9271
www.camcorpinc.com
( !, +0! 3 + 24
Compressed Air Manifold: Typically, CAMCORP ships the compressed
air manifold installed complete with diaphragm valves and solenoid
enclosure(s), except when units are over legal shipping width with them
in place .
Flanges: All bolts on flanges should be tight. All ports in the dust
collector not being used must be plugged prior to start-up.
Electrical: A 120 volt 60 Hertz circuit is required to operate the dust
collector’s pulse-jet cleaning system (unless a different voltage for
components was requested). This timer must be wired according to the
wiring diagrams and be provided with a circuit that is free from transient
currents. Do not over fuse.
The DWYER “Smart Timer” board has adjustable pulse duration and
interval (time between valves firing) settings. Since there are many
variances in operations and conditions these are presented only as initial
start-up guidelines. If you experience problems in cleaning of the filter
cartridges, please contact CAMCORP.
TIMER BOARD ADJUSTMENTS
(Recommended at start-up)
VALVE SIZE PULSE DURATION INTERVAL
1” .10 to .12 seconds 20 to 25 seconds
1-½” .06 to .08 seconds 20 to 25 seconds
2” .18 to .20 seconds 20 to 25 seconds
3-3
