Step 4: Platform and ladder, if applicable, can now be attached. Torque the
fasteners to the appropriate specifications.
All CAMCORP dust collectors are provided with lifting lugs for ease in
handling of the units during field erection and installation. The number and
location of these lifting lugs will vary depending on the model, size, and
weight of the dust collector. Before attempting to rig and lift your dust
collector, please review the certified general assembly drawing supplied from
CAMCORP to verify the number and location of the lifting lugs. Visually
check this information on the actual equipment also. Large units are
frequently shipped in several sections, so check the lifting lugs provided on
each section. If these cannot be used or there is some question about lifting
lug location consult the engineering staff at CAMCORP for proper location
since proper care must be taken to prevent damage to housing or its
components.
Rigging and Lifting Guidelines
Do not lift the dust collector by any attachments other than the lifting lugs
provided.
Use all of the lifting lugs provided on the dust collector or section of the
dust collector when making a lift.
If the lifting lugs are located below the roofline of the dust collector or
below the top of the section of the dust collector a vertical pull must be
made to avoid crushing the top of the unit. Use spreader beams to
accomplish this vertical pull.
Attach tag lines at several locations to help in controlling the unit when
lifted and to prevent spinning or swinging.
The dust collector should be lifted and lowered at a slow, uniform rate
and not allowed to bounce or joggle since this can cause excessive
impact stresses at the lift points.
3-2
