Fuses Usage
22 Driver Information Center (DIC)
23 Rear Wiper
24 Cooled Seats
25
Driver Seat Module, Remote Keyless
Entry System
26
Driver Power Door Lock (Unlock
Feature)
Circuit Breaker Usage
LT DR
Driver Side Power Window Circuit
Breaker
Harness
Connector
Usage
LT DR Driver Door Harness Connection
BODY Harness Connector
BODY Harness Connector
Center Instrument Panel Fuse Block
The center instrument panel fuse block is located
underneath the instrument panel, to the left of the
steering column.
Top View
Harness
Connector
Usage
BODY 2 Body Harness Connector 2
BODY 1 Body Harness Connector 1
BODY 3 Body Harness Connector 3
