Feed and Drain Connection
Feed Connection
1. Locate and turn off the angle stop val
will usually be located under the sink on the pipe
2. When the angle stop valve is closed,
tap on the sink.
3. Disconnect the cold water faucet feed line
4. Install the feed adapter into the angle
5. Firmly press the green 1/4” tubing int
6. Connect the cold water faucet feed line i
7. Make sure the small shut-off valve on the g
connection valve. Check for leaks.
7. Attach the small feed valve warning t
8. Attach the Shut-off Warning label to the
Date of Installation label and attach to the side of the
Drain Connection
1. You will need an electric drill with a 3/8” bit and a sc
installation.
2. Obtain the drain saddle assembly, tw
adhesive foam pad from the small parts bag (Fig. 2).
3. Place the adhesive foam pad on the inside of the d
4. Position the drain saddle on the drain pipe under the sink b
sink connection. Orient the drain saddle so th
5. Using the bolts and hex nuts, hand tig
the pipe snugly. Use a Phillips screwdriv
6. If necessary, remove the drain saddle
Using the connector opening in the side of the d
through the wall of the drain pipe.
7. Extend the drain tubing from the RO dispensing faucet to the drain saddle and measure
for length. The tubing must be routed so that water can run downhill for the entire length
of the tubing from the faucet. Avoid low spots or loops. Cut the tubing shorter
8. Insert the drain tube from the RO dispensing faucet through the drain saddle connector
nut. Tighten the connector nut onto the drain saddle.
ain Connection
alve on the cold water line feeding the sink. This valve
ed under the sink on the pipe coming out of the wall.
e is closed, relieve pressure in the line by opening the cold water
eed line at the angle stop valve.
o the angle stop. (Fig. 1)
nto the 1/4" connector on the feed adapter.
eed line into the feed adapter.
e on the green feed line is closed. Turn on the feed water
tag from the parts bag to the feed valve.
o the system so that it is directly visible. Fill out the
o the side of the system.
ou will need an electric drill with a 3/8” bit and a screwdriver for this portion of the
wo 1 ½” bolts, two 3/8” hex nuts, and the small
om the small parts bag (Fig. 2).
oam pad on the inside of the drain saddle front, aligning the holes.
ain pipe under the sink between the “P” trap and the
ain saddle so that the opening is on the side of the drain pipe.
tighten the saddle bracket evenly until the saddle grips
ver to fully tighten the bolts. Do not over tighten.
ain saddle connector nut from the opening of the drain saddle.
the side of the drain saddle as a guide, drill a 3/8" hole
Extend the drain tubing from the RO dispensing faucet to the drain saddle and measure
for length. The tubing must be routed so that water can run downhill for the entire length
of the tubing from the faucet. Avoid low spots or loops. Cut the tubing shorter, if necessary.
8. Insert the drain tube from the RO dispensing faucet through the drain saddle connector
nut. Tighten the connector nut onto the drain saddle.
7
e
er
er
the saddle grips
ain saddle.
Fig. 1
Note: The drain saddle
assembly must be installed
before the ‘P’ trap. Do not
install the drain saddle
assembly between the ‘P’
trap and the wall.
Fig. 2
