Making it all work!
a. Make sure both the Kenwood TH-D7 and AvMap
Geosat 6 APRS are turned OFF!
b. Connect the four pole 2.5mm communication cable
end to the serial port of the Geosat 6 APRS and the
three pole 2.5mm end to the D7A’s GPS receptacle.
IMPORTANT! These are easily reversed and hooked
up backwards; also when connecting to the Geosat
6 APRS make sure you plug into the serial port, not
the audio input.
Screen # Item Select/Enter
2-1 CALL SIGN {your call sign}
2-2 GPS UNIT {NEMA96}
2-3 WAYPOINT {9 DIGITS NEMA}
2-5 POS AMBIGUITY {OFF}
2-7 POS LIMIT {OFF}
2-B PACKET PATH {WIDE1-1,WIDE2-2}
2-C DATA TX {AUTO}
2-D PACKET TRANSFER INTERVAL
{3 MIN.} NOTE: Smaller times (<5min) are for mobile units while
stationary stations will use longer times (~10 min. and up)
2-N PACKET SPEED {1200 bps}
APRS Functions
