Making it all work!
a. Make sure both the Kenwood TM-D700 and AvMap
Geosat 6 APRS are turned OFF!
b. Connect the four pole 2.5mm communication
cable end to serial input of the Geosat 6 APRS and the
three pole 2.5 mm end to the D700’s GPS receptacle.
IMPORTANT! These are easily reversed and hooked
up backwards; also when connecting to the Geosat 5
make sure you plug into the serial input, not the ANT
receptacle which is right next to it and the same size!
Screen # Item Select/Enter
3-1 CALL SIGN {your call sign}
3-2 GPS UNIT- NEMA FORMAT {NEMA96}
3-3 WAYPOINT {9 DIGITS NEMA}
3-5 POS AMBIGUITY {OFF}
3-7 POS LIMIT {OFF}
3-B PACKET PATH {WIDE1-1,WIDE2-2}
3-C PACKET TRANSMIT METHOD {AUTO}
3-D PACKET TRANSFER INTERVAL
{3 MIN.} NOTE: Smaller times (<5min) are for mobile units while
stationary stations will use longer times (~10 min. and up)
3-J PACKET TRANSFER RATE {1200 bps}
APRS functions
