Insert the new bulb into the hole,
making sure the tabs are in their
slots. Pivot the hold-down wire
back in place, and clip the end into
the slot.
Install the rubber seal and make
sure it is right side up; it is marked
‘‘TOP.’’
Pull the battery back to its original
position, then install the bolt in the
hold-down, and tighten it securely.
Push the electrical connector onto
the tabs of the new bulb. Make
sure it locks in place. Turn on the
headlights to test the new bulb.
Install the neck of the windshield
washer reservoir on the bracket.
Then remove the bolt from the
battery hold-down, and carefully
push the battery toward the
windshield to obtain enough
working space.
Unclip the end of the hold-down
wire from its slot. Pivot it out of
the way, and remove the bulb.
Remove the rubber weather seal
by pulling on the tab.
Remove the electrical connector
from the bulb by pulling the
connector straight back.
3.
4.
5.
6.
7.
8. 2.
Lights
Driver’s Side
Ma
int
e
na
nce
173
HOLD DOWN
WIRE
BULB
WEATHER SEAL CONNECTOR
