Jaclo Gosh Concerto - 1730 - Manual (Page 7)

jaclo industries | 129 Dermody Street Cranford, NJ 07016
p 908.653.4433 | 800.852.3906 f 908.653.1717 | 800.852.4133
JACLO.COM
GOSH CONCERTO | PG 7
CREATED 5.27.10
Pressure (PSI) 14.5 29 43.5 58 72.5
Capacity (Gal) 1.8 2.9 3.5 4.1 4.65
THE ATTACHED TABLE DISPLAYS THE CAPACITIES OF THE SHOWER COLUMN ACCORDING TO THE SUPPLY PRESSURE VARIATIONS
ISTXX2492TK ING. 07.02.08. REV=00
ISTXX2492TK ING. 07.02.08. REV=00





 

     
     




ISTXX2492TK ING. 07.02.08. REV=00
ISTXX2492TK ING. 07.02.08. REV=00





 

     
     




32.75"
57"
15.75"
3.94"
54°
19.69"
4.72" 2.75"
4.41"
8.11"
