Hardy Enviro Bench Scales - Manual (Page 3)

Okidata 186T Form Printer
The Enviro™ Series should be programmed for Port 1 Output button, 9600 baud, 8 data bits, no stop bits,
and Hibusy.
To Change Menu Settings:
1. To enter MENU MODE, press and hold SELECT while turning on the printer. The “12” and
“UTILITY” LEDs will blink.
2. With the printer in the Menu Mode, press SELECT to print the complete menu. The current
default settings print out. It is recommended to use tractor fed paper.
Note: The printed menu selections are different for each emulation mode.
3. Press LINE FEED to select the relevant group that needs to be changed (the group is the left-hand
column on the Menu printout).
4. Press FORM FEED to select the relevant item within the selected group (the Item is the center
column on the Menu printout).
5. Press TOF SET to cycle through the settings available for the item you want to change (the
settings are the right-hand column on the Menu printout).
6. To continue making changes: press LINE FEED for the next group or press FORM FEED for the
next item. Repeat as needed until you are finished changing settings.
7. Press PITCH and MODE together to save the changes and exit the Menu Mode.
Notes:
Exiting the Menu Mode by turning off the printer will cancel any changed settings.
Printed menu’s changes per Printer Emulation Mode. If printer emulation mode is NOT set to ML, set this
first, then reprint the menu. Then set menu as follows:
(group) (item) (set)
(press LINE FEED to change) (press FORM FEED to change) (press TOF SET to change)
Printer Control
Font
Font
Font
Font
Font
Font
Symbol Sets
Symbol Sets
Symbol Sets Emulation Mode
Print Mode
DRAFT Mode
Pitch
Proportional Spacing
Style
Size
Character Set
Language Set
Zero Character
ML
Utility
SSD
10 CPI
No
Normal
Single
Standard
American
Slashed
0596-0317-01 Rev. A Page 3
