2| Product description
2.2 Name plate (example)
1
Type designation
6
Voltage, circuit, frequency
2
Machine number
7
Nominal rotation speed
3
maximum operating current
8
Displacement
4
Starting current (rotor blocked)
9
Voltage, circuit, frequency
5
ND LP: max. admissible operating pressure 10 Nominal rotation speed
(g)
Low pressure side
11 Displacement
HD (HP): max. admissible operating
12 Oil type filled at the factory
pressure
(g)
High pressure side
13 Terminal box protection type
Observe the limits of application
Electrical accessories can change
diagrams!
the IP protection class!
50 Hz
}
60 Hz
}
/
HG
4
3 e 380-4 S
X
2.3 Type key (example)
¹
)
HG - Hermetic Gas-cooled (suction gas-cooled)
²
)
X
- Ester oil charge (HFC refrigerant, e.g. R134a, R404A/R507, R407C)
3
)
S
- More powerful motor, e.g. for air-conditioning applications
1
2
3
4
5
13
12
7
11
6
10
8
9
19/28
SE 55
27,3
32,8
HGX34e/315-4
21,1/12,2A
111A
64A
IP66
Fig. 3
AS38125A001
R407C
Refrigerant
Motor variant
3
)
Number of poles
Swept volume
e-series
Numbers of cylinders
Size
Oil charge ²
)
Series ¹
)
