9| Dimensions and connections
SV
DV Suction line
Discharge line see technical data, Chapter 8
A Connection suction side, not lockable
1/8“ NPTF
A1 Connection suction side, lockable
7/16“ UNF
B Connection discharge side, not lockable
1/8“ NPTF
B1 Connection discharge side, lockable
7/16“ UNF
D1 Connection oil return from oil separator
1/4“ NPTF
E Connection oil pressure gauge
1/8“ NPTF
F Oil drain M10
H Oil charge plug
1/4“ NPTF
J1 Oil sump heater (accessories) Ø 15 mm
K Sight glass 1 1/8“- 18 UNEF
L1 Thermal protection thermostat
1/8“ NPTF
O Connection oil level regulator 1 1/8“- 18 UNEF
Dimensions in mm
Fig. 25
1) SV 90° rotatable
1)
Centre of gravity
273
230 310 46
ca.135
ca.165
79 419
F
A
H,D1
B1
E
L1
DV
J1
O,K
ca.315
272
115
4x 12
ca.285
B A
ca.540
A1
SV
A
10
40
30
M
20
Schwingungs-
dämpfer
273
230 310 46
ca.135
ca.165
79 419
F
A
H,D1
B1
E
L1
DV
J1
O,K
ca.315
272
115
4x 12
ca.285
B A
ca.540
A1
SV
A
10
40
30
M
20
Schwingungs-
dämpfer
HG34e R407C
Vibration
damper
