10 | dimensions and connections – GEA Bock HG8 User Manual
Page 35

D
GB
F
E
I
Ru
35
09790-11.2014-DGbFEIRu
SV
DV
Suction line
Discharge line see technicla data, Chapter 9
A
Connection suction side, not lockable
1/8“ NPTF
A1
Connection suction side, lockable
7/16“ UNF
A2
Connection suction side, not lockable
1/4“ NPTF
B
Connection discharge side, not lockable
1/8“ NPTF
B1
Connection discharge side, lockable
7/16“ UNF
C
Connectoin oil pressure switch OIL
7/16“ UNF
D
Connection oil pressure switch LP
7/16“ UNF
D1
Connection oil return from oil separator
1/4“ NPTF
E
Connection oil pressure gauge
7/16“ UNF
F
Oil drain
M22 x 1,5
H
Oil charge plug
M33 x 2
J
Connection oil sump heater
M22 x 1,5
K
Sight glass
-
L
Connection thermal protection thermostat
1/8“ NPTF
N
Connection capacity controller
M45 x 1,5
O
Connection oil level regulator
3 x M6
ÖV1
Oil service valve
7/16“ UNF
P
Connection oil differential pressure sensor
M20 x 1,5
Q
Connection oil temperature sensor
1/8“ NPTF
10| Dimensions and connections
