4 | compressor assembly – GEA Bock HG8 User Manual
Page 12

12
D
GB
F
E
I
Ru
09790-11.2014-DGbFEIRu
4| Compressor assembly
Rigid
fixed point
As short as
possible
4.5 Laying suction and pressure lines
A rule of thumb: Always lay the first pipe section starting from the shut-off valve downwards
and parallel to the drive shaft.
ATTENTION Improperly installed pipes can cause cracks and tears, the result
being a loss of refrigerant.
INFO
Proper layout of the suction and discharge lines directly after
the compressor is integral to the system’s smooth running and
vibration behaviour.
Fig. 15
