1. Use the supplied triangular key to open the door on the right side
of the device.
2. A red release grip can be found there that is attached to the
housing by a cylinder screw.
3. Use a SW 4 hex key to loosen and remove the cylinder screw that
holds the release grip. Put the screw aside.
4. Take a hold of the release grip and slowly pull the lock of the hood
open by the cable.
5. Once the hood is unlocked, the release grip can be reattached in
the housing by the cylinder screw.
6. The next time the device is switched on, the hood lock (4) is
returned automatically to its start position and work can continue.
2.7 Hazardous points
CAUTION!
Crushing hazard
– when closing the hood!
– when clamping the grinding set!
Safety information and use
