doepfer

System A - 100

Bus Access

A-185

3

3. Controls

1

Contr.

LED indicator 1 shows the state of the gate signal on
the system bus.

2

Contr.

LED indicator 2 gives a visual indication of the CV
present on the system bus.

4. In / Outputs

!

Gate In

Use gate input ! for patching in external gate si-
gnals
.

"

Gate Out • § Gate Out

The two internally linked gate outputs " and § pro-
vide access to any gate signal present in the internal
system bus.

$

CV In

Use CV input $ for patching in external CV signals.

%

CV Out • & CV Out

The two internally linked CV outputs % and & provide
access to any CV signal present in the internal system
bus.
