2. Overview
Controls:
1
CV 1 :
Coarse control for the voltage at
linked outputs ! and "
2
Fine :
Fine control for the voltage at linked
outputs ! and "
3
CV 2 :
Coarse control for the voltage at
linked outputs § and $
4
Fine :
Fine control for the voltage at linked
outputs § and $
5
CV 3 :
Control for the voltage at output %
Outputs:
!
, " CV 1 :
Parallel outputs for CV source one
§
, $ CV 2 :
Parallel outputs for CV source two
%
CV 3 :
Output for CV source three
CVS
CV 1
CV 1
Fine
➀
➁
➂
➃
➄
Contr. Volt. Source
0
10
0
10
CV 2
CV 2
Fine
0
10
0
10
0
10
CV 3
CV 3
