A-171, System a - 100, Overview – Doepfer A-171 VC Slew Limiter User Manual
Page 2: Vcsl, Doepfer
A-171
VC Slew Limiter
System A - 100
doepfer
2
2. Overview
Controls and indicators:
1
Rate :
control governing the transition speed
of the modified signal
2
CV 2 :
attenuator for control voltages at "
3
LEDs :
status indicators for voltages at
output %
In / Outputs:
!
CV 1 :
input for voltages to control transition
speed
"
CV 2 :
ditto, but with level controlled by
attenuator 2
§
Sign. In :
signal input
$
Sign. In :
ditto, interconnected with § (and so a
"mini multiple")
%
Out :
output
VCSL
CV 2
Sign. In
CV 2
Rate
CV 1
➀
➁
➂
VC SLEW LIMITER
0
10
0
10
Out
Control
- +
