A-165, System a - 100, Overview – Doepfer A-165 Dual Trigger Inverter/Modifier User Manual
Page 2
A-165
Dual Trigger Modifier
System A - 100
doepfer
2
2. Overview
Indicators
1
LED :
Status indicator for the inverted trig-
ger signal at output §
2
LED :
Status indicator for the trigger pulse
generated, and available at output $
In / Outputs
!
In :
Input for trigger signal
"
In :
ditto, linked to input !
§
Inv. Out :
Output for the inverted trigger signal
$
+/- Out :
Output for the trigger pulses genera-
ted by the A-165
A-165
In
TRIG. MODIF.
In
Inv.
Out
+/-
Out
In
In
Inv.
Out
+/-
Out
➀
➁
