Page 2: Overview, Doepfer, Dual trigger delay, Controls and indicators
A-162
Dual Trigger Delay
System A - 100
doepfer
2
2. Overview
Controls and indicators:
For each trigger delay:
1
Del. :
Delay control
2
Len. :
Trigger length control
3
LED :
Trigger pulse output indicator
In / Outputs:
!
In :
Trigger signal input
"
Out :
Output
A-162 TDEL
Out
Control
Len.
Del.
In
➀
➁
➂
DUAL TRIGGER DELAY
0
10
0
10
Out
Control
Len.
Del.
0
10
0
10
In
