Doepfer A-149-1 Quantized/Stored Random Voltages - Manual (Page 2)

A-149 /1 RCV System A - 100 doepfer
2
2. Overview Controls and Indicators :
1 Man N : manual control of “N”
2 CV N : attenuator for CVN at input !
3 , 4 LED : display for output § resp. $
5 Man D : manual control of distribution "D"
6 CV D : attenuator for CVD at input &
7 , 8 LED : display for output / resp. (
In - / Outputs:
! CV N In : CV input for “N”
" Clk In : clock input for Quantized RCV section
§ n+1 : N+1 states output
$ 2 n : 2 n states output
% CV D In : CV input for distribution “D”
& Clk In : clock input for Stored RCV section
/ : output with equal probability distribution
( : output with adjustable probability distri-
bution (D)
➌
➍
➊
➋
➀
➂
➁
➃
➐
➑
➆
➇
➎
➏
➄
➅
