Quad ADSR A-143-2

System A-100

DOEPFER

DOEPFER

DOEPFER

DOEPFER

4

Controls:

1

Range :

range switch low – high – medium

2

Attack :

attack control

3

Decay :

decay control

4

Sustain :

sustain control

5

Release :

release control

6

:

envelope display (LED)

Inputs and Outputs:

!

G :

gate input
(gate inputs 2…4 are normalled to
gate input 1)

"

End of A :

end of attack output

§

End of D :

end of decay output

$

Rt :

retrigger input

%

End of R :

end of release output

&

ADSR Out:

envelope output

The controls and outputs are the same for all four units.

Module width: 26 HP / 131.8 mm
Module current: 70 mA
