Page 2: Doepfer, Fixed filter bank, Controls
A-128
Fixed Filter Bank
System A - 100
doepfer
2
2. A-128 - Overview
Controls:
1
50 ... 11000 : Amplitude controls (attenuators) for
the individual band pass filters
In / Outputs:
!
Audio In :
Signal input
"
Audio Out : Signal output
A-128
FIXED FILTER BANK
Audio In
➀
Audio Out
3600
5200
7500
11000
2200
0
10
0
10
0
10
0
10
0
10
500
750
1100
1600
350
0
10
0
10
0
10
0
10
0
10
75
110
150
220
50
0
10
0
10
0
10
0
10
0
10
