A-118 NOISE / RANDOM System A - 100 doepfer
4
Fig. 2: Random voltage with Rate = 0
Fig. 3: Random voltage with Rate = 10
4 Level
The amplitude of the signal at output § is adjusted with
this control.
5 Random Control
Use these two LEDs to keep track of whether the
random voltage is positive (+) or negative (-) at any
point in time. Their relative brightness also shows
amplitude.
4. Outputs
! White
Output ! produces white noise.
" Colored
Output " produces coloured noise, whose spectrum
is determined by the position of controls 1 and 2.
§ Random Output
Output § produces a random voltage, whose rate of
change and amplitude are determined by controls 3
and 4.
