System a - 100, A-101-3, User examples – Doepfer A-101-3 Vactrol Modular Phase Filter User Manual
Page 9
doepfer
System A - 100
Modular Vactrol Phaser
A-101-3
9
(
Stage Out (6x)
These are the outputs of the phase shifting stages.
Applications of these outputs have been described on
the preceding pages. The output of stage 6 is normalled
to socket § Shifted Audio In and to the left one of the two
sockets % Polarizer In.
5. User Examples
not yet ready
