AUGER SYSTEM
32
Auger housing disassembly: flight removal
There are four individual auger flies. The flies draw snow inward to the impeller. If any one flight is damaged, it can be
replaced individually.
1. Remove the auger shaft assembly, complete with the auger
transmission, impeller shaft, and impeller. See Figure 4.21.
2. Remove the auger shaft bearings and washers.
See Figure 4.22.
3. Remove the bow tie clips and shear pins that transfer
power to the flights from the auger shaft.
4. Slide the flights off of the auger shaft
IMPORTANT: Keep track of the spacers in between the
flights; replace them if they show signs of wear.
Figure 4.21
Flights
Figure 4.22
Bearing housing
Washer
