AUGER SYSTEM
25
Auger control cable replacement
1. Remove the belt cover as described in the “BELT
REMOVAL” section of this chapter.
2. Slip the cable off of the cable guide pulley located on the
left side of the frame. See Figure 4.6.
NOTE: It may be necessary to loosen the screw that holds
the cable guide pulley using a 3/8” wrench.
3. Use the slack created by the previous step to unhook the Z-
fitting at the top end of the cable from the auger control bail.
See Figure 4.7.
4. Cut the cable ties that hold the cables to the handle bars.
NOTE: On three-speed models, the cable passes through
the speed control housing on the handlebars.
5. Remove the phillips head screws that hold the two halves of
the speed control housing together. See Figure 4.8.
Figure 4.6
Cable
Cable guide
Figure 4.7
Auger control bail
Z-fitting
Auger control cable
Figure 4.8
Speed control housing
