AUGER SYSTEM
27
11. Unbolt the auger cable control bracket from the right side of
the frame using a 3/8” wrench.
12. Release the auger control cable from the bracket on the
right side of the frame. See Figure 4.12.
13. Install the replacement cable by reversing the removal pro-
cess.
14. Check and adjust the cable bracket any time the auger belt
or auger cable have been replaced;
14a. With the auger control bail engaged, the spring that
connects the cable to the brake arm should be
stretched a total of .080”.
14b. With the auger control bail released, the cable should
be slack.
14c. Loosen the bracket bolts and slide the bracket to tighten or loosen the cable.
15. With the belt cover installed, test the operation of all features of the snow thrower before returning it to service.
Disconnecting
the cable
Figure 4.12
Cable bracket
