23
For parts or
accessories, contact
your local Cub Cadet
dealer. To locate the
dealer nearest you
call 877-282-8684
or log onto
www.cubcadet.com.
8
Specifications
Engine/Electrical
Make 20HP** Kohler Command®
V-Twin OHV
Type\Cylinders 4 Cycle Gas/2 Cylinders
Displacement 38.0 cu. in. (624cc)
Maximum Torque 32.6 lb/ft @ 2600 RPM
Ignition Transistor Controlled
Lubrication Full Pressure w/Filter
Speed (No Load) 1,200 RPM (idle) / 3,850 RPM (fast)
Cooling System Air
Air Cleaner Replaceable, dual element
Battery 500 Cold Cranking Amps
Alternator 12 Volt-15 Amp Regulated
Headlights Two, 37.5 Watt Incandescent
Wiring Automotive - Style Fused Control
System
Suspension Front & Rear - Fully Independent
Dual A-Arms with Coil Over
Shocks
Fuel System
Capacity 7 Gallons
Low Fuel Indicator Dash-mounted Indicator Light
Transmission
Type Continuously Variable (CVT -
With CVT Cover)
Differential Lock Rear - Standard
Hand Operated
Front - Flip Switch in Dash
Drive Chain N/A
Ground Speed 0-25 mph
Trans axle Fully Enclosed, Oil Bath
Gear Selection Forward Hi-Low, Neutral,
Reverse
Overall Reduction Ratio Low 29.8:1 / High 16.7:1
Rear Axle Housing
Cast Iron
Operation
Brake Type Four Wheel 8” Hydraulic Disc
Parking Brake Hand Operated Mechanical Disc
Steering
Rack & Pinion
Dimensions
Length/Width 119” x 63.5”
Tread Center F: 52” / R: 50”
Height (Overall) 73”
Wheelbase 78.0”
Weight
(Incl. Fuel & Fluids) 1,600 lbs.
Ground Clearance
(Under Transaxle) 10.5” to Differential
Ground Clearance
(Under Foot Platform) 9” Front
9.5” Rear
Turn Clearance Circle 22.0 ft.
Bed 51 5/8” L x 42” W x
11 1/2” ”H
Capacity
Volume - Cargo Box 14.4 cu. ft.
Cargo Box Capacity 900 lbs.
Seating-Capacity/Type 2 / Professional High Back
Towing Capacity
1,300 lbs.
Payload Capacity* 1,300 lbs.
Cargo Box
Material 14-Gauge Steel
Attachment Rubber Isolated
Features
Rear Hitch Standard 2” Rear Receiver
Dual Cup Holders Standard
Additional Storage Dash Box
Power Port 12V, Dash Mounted
Front Bumper Standard
Front Brush Guard Standard - (Front bumper
req.)
Electric Bed Lift Optional
Rubber Floor Mats † Optional
Horn Optional
Tires
Trail Front 25” x 10” - 12”
Trail Rear 25” x 11” - 12”
Trail Front (Radial) †† 26” x 10” - 14”
Trail Rear (Radial) ††
26” x 12” - 14”
Turf ‡ 24” x 9.50” - 12”
*Includes 200 lb. operator, 200 lb. passenger, and maxi-
mum bed capacity.
**As rated by engine manufacturer.
† Standard on Camo and Limited Edition Units
NOTE: Specifications subject to change without notice.
†† Limited Edition
‡ 4x2
