Cub Cadet Series C470 - Manual (Page 17)

17
Replacing Headlight Bulbs
1. Raise hood to get access to the headlight assembly.
2. Turn the bulb/socket assembly approximately a
quarter turn counterclockwise to align its tabs with
the notches of the reflector, then remove from the
reflector. See Figure 6.
3. Unplug the wire harness from the bulb/socket
assembly.
4. Plug the new bulb/socket assembly into the wire
harness.
5. Align the tabs of the new bulb/socket assembly with
the notches of the reflector and insert the bulb. Turn
the bulb/socket assembly clockwise to lock in place.
6. Lower and secure hood.
Fuses
1. Unlatch and lift hood forward to get access to under
the dash panel.
2. Remove fuse holder cover. See Figure 7.
3. Remove the appropriate electrical fuse and replace
with proper amperage fuse.
4. Lower and secure hood.
Tire Pressure
WARNING: Explosive separation of
tire and rim parts is possible when
they are serviced incorrectly. Do not
stand in front or over tire assembly
when inflating.
The recommended operating tire pressure is ap-
proximately 14-18 psi for all tires. Overinflating above
recommended tire pressure can reduce the life of the tire.
Check tire pressure before driving the vehicle.
Wheel Replacement
WARNING: Using an unstable lifting
device and vehicle support may result
in bodily injury. Use a safe lifting
device and supports to work on raised
vehicle.
1. Stop the vehicle on a level surface and apply parking
brake.
2. Turn the ignition key to the STOP position and remove
the key.
3. Loosen but do not remove the five lug nuts from the
axle hub. See Figure 8.
WARNING
Figure 6
Figure 7
Servicing
Your
Utility
Vehicle
Explosive separation
of tire and rim parts is
possible when they are
serviced incorrectly.
Do not stand in front
or over tire assembly
when inflating.
Using an unstable lift-
ing device and vehicle
support may result in
bodily injury. Use a
safe lifting device and
supports to work on
raised vehicle.
Figure 8
