18
4. Raise rear/front of vehicle with a safe lifting device
and place support stands under vehicle frame.
WARNING: When lifting the rear of
the vehicle for any reason, DO NOT
engage the wheels. Even if the 4x4
switch is in the OFF position, there
is a possibility that the front wheels
may engage if the rear wheels are spinning fast
enough.
5. Remove the five lug nuts and the wheel. Place new
wheel on the axle hub and secure with nuts.
6. Tighten nuts diagonally until snug.
7. Remove support stands and lower vehicle.
8. Finish tightening the nuts to 65-75 lb-ft using a
torque wrench.
Maintenance of the Operator
Protective Structure (OPS)
Periodically (at least every six months) visually inspect
the OPS for damage and loose fasteners. If damage is
noted, contact your Cub Cadet dealer.
If an accident has occurred which may have damaged the
OPS, have the OPS thoroughly inspected by your Cub
Cadet dealer.
WARNING: To ensure the struc-
tural integrity of the OPS to provide
operator protection, do not attempt
to straighten or weld the OPS. A
damaged OPS should be replaced.
If the OPS is removed for any reason, make sure the
proper hardware is used to reinstall it, and that the recom-
mended torque values are applied to the fasteners.
If you are not installing new bolts when replacing or
reinstalling the OPS, apply Loctite ® 242 to the threads
of the bolts that were removed. Torque the bolts to
32 to
36 ft. lbs .
Changing Transfer Case Oil
WARNING: The fluid for your
transmission has been specially
formulated to ensure the safe and
proper operation of your vehicle.
When changing the transmission
fluid replace it with 80W-90 Shell Dentax Low Foam
Oil. Failure to use 80W-90 Shell Dentax Low Foam
Oil may result in a failure of the drive system which
could result in property damage or personal injury.
DO NOT substitute.
1. Park vehicle on level surface, place shift lever in
Neutral, and apply parking brake.
2. Allow transmission sufficient time to cool before
attempting any maintenance or repairs.
3. Raise and secure cargo box, if manual lift.
4. Access drain plug through slot on underside of
machine and remove plug. See Figure 9.
$RAIN
0LUG
&ILL
0LUG
/IL
#AP
Figure 9
WARNING
Servicing
Your
Utility
Vehicle
The fluid for your
transmission has been
specially formulated
to ensure the safe and
proper operation of
your vehicle. When
changing the transmis-
sion fluid replace it
with Shell Dentax
80W-90 Low Foam Oil.
Failure to use Shell
Dentax 80W-90 Low
Foam Oil may result
in a failure of the drive
system which could
result in property dam-
age or personal injury.
DO NOT substitute.
When lifting the rear
of the vehicle for
any reason, DO NOT
engage the wheels.
Even if the 4x4 switch
is in the OFF position,
there is a possibility
that the front wheels
may engage if the rear
wheels are spinning
fast enough.
