NVR User Manual
27
5.4.2 Motion
This tab allows to setup schedule for motion based recording.
Step1: Enter into MenuSetupScheduleMotion tab. Refer to Fig 5-16:
Step2: The setup steps for schedule for motion based recording are similar
to normal schedule setup. You can refer to 5.4.1 Schedule for details.
Note: The default schedule of motion based recording is 24x7, that is, the color
of schedule settings interface is dark blue. This enables motion based recording
for 24x7. If you want to activate motion based recording, you must enable
motion alarm and setup schedule for motion alarm (Refer to Chapte5 5.5.2
Motion Alarm for more details).
Fig 5-16 Schedule Configuration-Motion
5.4.3 Sensor
This tab allows to setup schedule for sensor based recording.
Step1: Enter into MenuSetupScheduleSensor tab. Refer to Fig 5-17:
Step2: The setup steps for schedule for sensor based recording are similar to
normal schedule setup (Refer to 5.4.1 Schedule for details).
Note: The default schedule of sensor based recording is 24x7, that is, the color
of schedule settings interface is dark blue. This enables sensor based recording
for 24x7. If you want to activate sensor based recording, you must enable
sensor alarm and setup schedule for sensor alarm (Refer to Chapter 5.5.1 for
more details).
Fig 5-17 Schedule Configuration-Sensor
5.5 Alarm Configuration
Alarm configuration includes four sub menus: sensor, motion, other alarm and alarm out.
