DVR User Manual
33
password. Once the setup is completed, your DVR will automatically dial up into your network.
Step 4: No matter what kinds of way to connect internet, you should test the effectiveness of the network by clicking “Test” button after
you setup the network.
Step 5: If the network is well connected, please click “Apply” button to save settings.
4.6.2 Sub-stream
Step 1: Enter into MenuSetupNetwork Sub-stream tab. Refer to Fig 4-28:
Step 2: Select fps, resolution, quality, encode and max bit rate
Step 3: Select “All” to set the same settings for all channels.
Fig 4-28 Network Sub-stream
4.6.3 Email
Step 1: Enter into MenuSetupNetworkEmail tab. Refer to Fig 4-29:
SMTP Server/Port: The name and port number of SMTP server. Check the SSL checkbox if the server requires a secure connection
Parameter Meaning
FPS Range from: 1-25 (PAL)/1-30(NTSC)
Resolution Support CIF
Quality
The higher the value is, the clearer the
record image. Six options: lowest, lower,
low, medium, higher and highest.
Encode VBR and CBR
Max Bitrate Range from: 256kbps~1792kbps
