DVR User Manual
8
Item Name Description
1 HD SD Video in HD SDI video signal inputs.
2 Alarm in Alarm Inputs for connecting sensors
3 HDMI port Connect to high-definition display device
4 VGA port VGA output, connect to monitor
5 LAN Network port
6 USB port
To connect external USB devices like USB flash drive, USB HDD for backup or
updating firmware.
7 GND Grounding
8 K/B Connect to keyboard. A is TX+, B is TX-.
9 P/Z Connect to speed dome. Y is TX+, Z is TX-.
10 CVBS CVBS output
11 Audio out Audio output, connect to the sound box
12 MIC in Talk. Connect to microphone
13 Alarm out Relay Output. Connect to external alarm.
14 Audio in Audio input
15 E-SATA Connect to HDD for backup.
2.4 Remote Controller
It uses two AAA size batteries.

Open the battery cover of the Remote Controller.

Place batteries. Please take care of the polarity (+ and -).

Replace the battery cover.
