COP-USA ASH56NVIR-L36S User Manual
Page 10
8
Speed Dome Address=1
ON
1
2
3
4
5
6 7
8
9 10
Speed Dome Address=2
ON
1
2
3
4
5
6 7
8
9 10
Speed Dome Address=3
ON
1
2
3
4
5
6 7
8
9 10
Speed Dome Address=4
ON
1
2
3
4
5
6 7
8
9 10
Speed Dome Address=18
ON
1
2
3
4
5
6 7
8
9 10
Speed Dome Address=1023
ON
1
2
3
4
5
6 7
8
9 10
a. The address of the dome camera is set according to the binary coding system in which ON means “1” and
OFF means “0”.
b. The coded addresses shown above are only from 1 to 18 and those from 19 to 1023 are and so forth.
c. Setup of the protocol: the protocol is set up by the first four bits of SW2 and the baud rate is set up by
the later two bits. Please refer to the following table and set the protocol and the baud rate to be identical
with that of the main machine.
3．Selection of the Protocol and the Default Baud Rate:
SW2 is used to set the communication protocol and the baud rate used by the pan/tilt. Bits from DIP-4 to DIP-1 of
the SW2 are used to select the protocol and 16 different protocols can be selected in maximum. The encoded table
of the protocol selected by the pan/tilt is as follows:
4．Setup of the Baud Rate of Communication of the Pan/Tilt（later 2 bits of SW2）
Position of Dip-Switch
Baud Rate of Communication
1 2 3 4 5
6
2400 bps
OFF
OFF
4800 bps
ON
OFF
9600 bps
OFF
ON
19200 bps
ON
ON
Type or Protocol
Selection of Communication
Protocol
Normal Baud
Rate
DIP-1 DIP-2 DIP-3 DIP-4 DIP-5 DIP-6
SAMSUNG
ON
OFF
OFF
OFF
OFF
ON
B01
ON
OFF
OFF
OFF
OFF
ON
NEON
ON
OFF
OFF
OFF
OFF
ON
Santachi
OFF
ON
OFF
OFF
OFF
ON
PELCO-D
ON
ON
OFF
OFF
OFF
OFF
PELCO-P/4800
OFF
OFF
ON
OFF
ON
OFF
PELCO-P/9600
OFF
ON
PANASONIC
ON
OFF
ON
OFF
OFF
ON
Longcomity
OFF
ON
ON
OFF
OFF
ON
HUNDA600
ON
ON
ON
OFF
OFF
ON
LILIN
OFF
OFF
OFF
ON
OFF
ON
VICON
ON
OFF
OFF
ON
ON
OFF
MOLYNX
OFF
ON
OFF
ON
OFF
ON
KALATEL
ON
ON
OFF
ON
ON
OFF
VCL
OFF
OFF
ON
ON
OFF
ON
Reserved
ON
OFF
ON
ON
OFF
ON
ALEC
OFF
ON
ON
ON
OFF
ON
Ultrak
ON
ON
ON
ON
OFF
ON
