I. Brief introduction
The keyboard controller is used for terminal receivers such as the intelligent Speed Dome and the decoder etc.
Taking the EIA/RS-485 electrical interface between the keyboard and the receiver, one keyboard can control as
much as 32 speed dome and decoders without driving the bus and the maximum communication distance between
the keyboard and the receiver is up to 1.2 km. It’s very easy for operating and setting the Speed Dome Camera.
The controller is also to control the terminal receiver to achieve the function of controlling pan/tilt, lens and ect.
Main Functions:
‹ Set the address range of the dome camera and the decoder：0～255.
‹ Control all functions of the dome camera such as Power ON/OFF.
‹ To operate the pan/tilt of Speed Dome Camera moving in different speed lever
‹ Set or call the set points and cruise tracks of the dome camera. Altogether 128 preset points and 6 cruise
tracks can be set. Each track involves 16 preset position and the dwelling time and call speed upon each
point can be set as well.
‹ Manually or automatically control the dome camera, and change the leaving settings of particular camera
by call the menu of the camera. .
‹ Manually control the focus, zoom and iris of the camera.
II. Introduction of Functions：
Select Camera（0~255）
Joystick Control Control pan/tilt direction and speed of the holder.
Lens Control Control the focus, zoom and iris of the camera
Operation of Preset Position （1~128）
Set Preset Position
Call Preset Position
Operation of Cruise Track（1~6）
Set Cruise Track
Run Cruise Track
Automatic Horizontal Scan Control of dome (including speed and direction of scan)
Self-Learning Track of Intelligent Speed Dome
Function Setting of Menu of Speed Dome
Control of Multiplexer
Direct Control on Decoder Control front devices such as the decoder etc.
III. Introduction of the keyboard Panel
1. The Sketch of the Front Panel and Description of Buttons (Figure 1)
There are speed joystick, buttons and LCD on the front panel of the control keyboard. The display is used to show
the status of the system as well as operation information. The joystick controls the upward, downward, leftward
and right ward speed motion of the speed dome. The description of buttons is as follows:
