7
View
Delete
-removes a batch completely from memory. The
name is deleted and its datasets are erased.
Close
-stops the recording process, closes the current
batch, and removes batch information from the
display.
First to appear is a graph of
individual data points as
shown in Figure 1. Scroll
through each dataset
parameter using the (-).
Press or (+) button to
view batch statistics and
individual datasets (see Figure 2).
Figure 1
-lists all datasets beginning with the current or most
recently used batch.
Open
-selects a previously created batch name to open
and make current. The current batch name and
number of stored datasets will be displayed.
To exit press (-)(+) buttons simultaneously.
Scroll datasets using the (-) or
(+) buttons. Hold for 1 second
to scroll a page at a time.
- Average
- Standard Deviation
- Minimum value
- Maximum value
To return to graph view or to exit press .
Figure 2
Shortcut:
