2.0 O VERVIEW
2.1 Gauge
ON/OFF
Switch
ZERO Key
LCD Display
PROBE
STATISTICS
Key
14
9.0 M EASURING L IMITS
Minimum Radius for Convex Surfaces 0.2" (5mm)
Minimum Radius for Concave Surfaces 2" (50mm)
Minimum Headroom
2" (50mm)
Minimum Sample Diameter 0.4" (10mm)
Minimum Substrate Thickness - F 0.020 mils (0.5 mm)
Minimum Substrate Thickness - NFe 0.002 mils (0.05 mm)
3
2.0 O VERVIEW
2.1 Gauge
ON/OFF
Switch
ZERO Key
LCD Display
PROBE
Battery Compartment
(On rear)
Battery Compartment
(On rear)
STATISTICS
Key
14
9.0 M EASURING L IMITS
Minimum Radius for Convex Surfaces 0.2" (5mm)
Minimum Radius for Concave Surfaces 2" (50mm)
Minimum Headroom
2" (50mm)
Minimum Sample Diameter 0.4" (10mm)
Minimum Substrate Thickness - F 0.020 mils (0.5 mm)
Minimum Substrate Thickness - NFe
0.00 2 mils (0.05 mm)
