AVF Group ZML8351: Flat & Tilt TV Mount for ANY WALL - Manual (Page 22)

I
P
Fitting the Wall Bracket
14
Use the correct fixings for your wall type. Mixing fixing screws may be required for
installations that span different wall types. DO NOT OVER TIGHTEN SCREWS.
Solid Wall
10mm (25/64")
40mm (1 9/16 ")
5.5mm (7/32")
N
O
N
M
Q
M
Remove dust
from holes
Lubricate screw
thread with soap
12.5 mm (½") MAX
75mm (3")
K
Lubricate screw
thread with soap
K
I
10mm (25/64")
108mm (4 1/4 ")
If gap is above 40mm (1
9/16
) use
plasterboard fixing method
Self drilling
40mm (1 9/16 ")
MAX gap
Dot & Dab
Remove dust from holes
A+B A+B
O
Tilt Position only
