Next, use the Wall Brackets and as a template and position them over the appropriate
PENCIL MARKS you have made, so that the mark is in the middle of the
CENTRAL HOLE of the Wall Bracket. Ensure the bracket is level and mark the three
DRILL POINTS with a pencil. Repeat for other bracket. A B
Drill six 3mm pilot holes and select appropriate fixings (see section 14)
Represents the
centre of your TV.
