AVF Group ZML2401: Flat & Tilt TV Mount for ANY WALL - Manual (Page 14)

17 Alternative Hanger Configurations
1 Spacer Combination 2 Spacer Combination 3 Spacer Combination
Top Fixings
Q
Bottom Fixings
When is it necessary to use red spacers?
D
2 - x4
TV TV
D
1
D
2
It is recommended that when fitting Tilt Brackets ( )
to your TV you have at least 5-10mm of screw
engagement. In certain circumstances you may need
to use red spacers (
) as either a replacement, or
together with spacers ( ) to achieve this. Whenever
you use red spacers (D2) you must use all 4 provided.
O
D2
D1
Problem
Not enough
screw engagement
Solution
Red spacer (D2) has
replaced spacer (D1)
*
If using screws use Adapter (E
1
) (F
2
), (F
3
) & (F
4
)
If using screws (F
6
), (F
7
) & (F
8
) use Adapter (E
2
)
If using screws (F
10
), (F
11
) & (F
12
) use Adapter (E
3
)
If using screws (F
14
), (F
15
) & (F
16
) no Adapter required
D 1
Q
D
1
F
4, 8, 12, 16
E 1, 2, 3
P
F 4, 8, 12, 16
E
1, 2, 3
P
Q
Bottom Fixings
D 1
Q
F
3, 7, 11, 15
E 1, 2, 3
P
F 3, 7, 11, 15
E
1, 2, 3
P
D 1
Q
Bottom Fixings
D
1
Q
F
2, 6, 10, 14
E 1, 2, 3
P
F 2, 6, 10, 14
E
1, 2, 3
P
D
1
Top Fixings Top Fixings
Alternative spacings can be achieved using the spacer / screw combinations shown in this section.
