ALFA NETWORK AWUS048NH - Manual (Page 56)

Wireless 11N USB Adapter
Items Information
SSID AP name of user type.
BSSID The IEEE MAC address of locally-managed, generating from a 46 random
code.
AID Raise value by current connection.
MAC Address The station MAC address of current connection.
Life Time (mm:ss) Record life time.
Click the “Config” button, then you can configure the wireless network properties. This page
provides overall configuration to this adapter.
SSID: AP name of user type.
Channel: Manually force the AP using the channel. System default is channel 1.
Security Setting: Authentication mode and encryption algorithm used within the AP. System
default is no authentication and encryption.
Cancel: Cancel the above changes.
OK: Apply the above changes.
- 56 -
