Figure 7
Figure 6
Servicing Tips
Right Column Monitor Removal:
Reach fingers between the wall and the right monitor
and lift the locking arm (Figure 7). Slide and pull
monitor to the right (about 3/4” ) until its button fittings
disengage from the frame, then remove.
Left Column Monitor Removal:
Reach fingers between the wall and the left monitor
and lift the locking arm. Slide and pull monitor to the
left (about 3/4”) until its button fittings disengage from
the frame, then remove.
