WWW.STIEBEL-ELTRON-USA.COM SUNWARMTH
™
CIR INFRARED HEATER|
19
EN
G
L
IS
H
INSTALLATION
APPLIANCE HANDOvER
14. Remove the heat lamp retainer clips both ends of lamps.
»
One clip at each end of heater
»
Two clips in the center of heater:
10. Appliance handover
Explain the functions of the appliance to the user. Draw special attention to the safety information. Hand the operating and installation
instructions to the user.
11. Specification
11.1 Dimensions - CIR 150-1 I
#10
Ø8.5
M8
3-Ø13
1 9/16˝
(40)
4 5/16˝
(110)
1 3/16
˝
(29.5)
8˝
(203)
6 11/16
˝
(170)
3 1/8˝
(80)
1 1/2
˝
(38)
3 5/8
˝
(92.5)
3/8
˝
(10)
2 1/2˝
(63)
1 5/8˝
(42)
1 1/4˝
(32)
1 5/8
˝
(42)
1/2˝
(13)
1 1/4
˝
(32)
5 11/16
˝
(145)
11/16
˝
(17)
3 3/4
˝
(95)
5/8
˝
(16)
5/8
˝
(16)
1 5/16
˝
(33)
5 11/16
˝
(145)
1 9/16˝
(40)
15 9/16˝
(395)
4 7/16
˝
(112)
15. The heat lamp is very fragile - handle and assemble with great
care!
»
Carefully slide old heat lamp out of heater through rectangular
slot in end of reflector.
»
CAREFULLY install new heat lamp and clip in place.
»
Reverse steps above to reassemble the heater.
»
Take particular care not to damage the lamp at Step 14 and
Step 13:
Rear
Top
Front
inches
(mm)
