Page 10
DWG.
REF.
NO.
DESCRIPTION HPB11
ITEM
NO.
HPB15
ITEM
NO.
HPB22
ITEM
NO.
39. Core Blower Wheel 1020002R 1020002R 1020002R
40. Slam Gate Interlock Switch 1024004 1024004 1024004
41. Slam Gate Melt Link 1159005 1159005 1159005
42. Slam Gate Melt Link Linkage 1140236 1140236 1140236
43. Slam Gate Actuator Complete 1141131 1141131 1141131
44. Air Discharge High Limit 1012012R 1012012R 1012012R
45. Air Discharge Controller 1040053R 1040053R 1040053R
46. Inlet/Outlet Plenum Assembly 1190004 1190004 1190004
47. Motor Run Capacitor 1018017 1018017 1018017
48. Circuit Breaker Standoff 1140139 1140139 1140139
49. Charge Control Resistor 1017027 1017027 1017027
50. Hardboard Base Insulation 1050060 1050061 1050061
51. Charge Control Circuit Board (SFIII) 1023005 1023005 1023005
52. Low Temperature Duct Sensor 1040054R 1040054R 1040054R
53. Charge Control Thermostat Assembly 1040033R 1040033R 1040033R
54. Fan Relay 1018008 1018008 1018008
55. 40VA Control Transformer 1017034 1017034 1017034
56. Electrical Panel 1140072 1140072 1140072
57. Stage 2 Time Delay Sequencer 1019000 1019000 1019000
58. Charging Sequencers 1019002 1019002 1019002
59. 15 Amp Circuit Breaker – GE Brand*
15 Amp Circuit Breaker – Siemens Brand* 1024012R
1024000R 1024012R
1024000R 1024012R
1024000R
60. 60 Amp Circuit Breaker (208/240V) – Siemens Brand*
60 Amp Circuit Breaker (208/240V) – GE Brand*
60 Amp Circuit Breaker (277V) – GE Brand* 1024002R
1024013R
1024014
1024002R
1024013R
1024014
1024002R
1024013R
1024014
61. Outdoor Air Temperature Sensor Assembly 1040032 1040032 1040032
62.
285o Core Temperature Control
N/A N/A 1040039
* When replacing breakers in a Steffes heating system, it is important to replace with like brand heaters.
