ASSEMBLY
1
2
17
Hitch Pin
Qty. 1
Wheel Bushing
Qty. 1
“Cone” side of wheel against leg
Insert the front and rear leg assemblies into tank support bracket and leg extender.
Front Leg Assembly
Rear Leg Assembly
Tank Support Bracket
Leg Extender
Wheels
Turn assembly upside down.
Insert axle rod through wheel, legs, tank support bracket and the other wheel. Attach with wheel bushing and hitch pin.
Axle Rod
Wheel
Wheel
Wheel Bushing
Hitch Pin
