PARTS LIST

15

Key Qty Description

A

1

FIREBOX

B

1

LID

C

1

LOGO PLATE

D

1

HOSE VALVE REGULATOR ASSEMBLY

E

1

CONTROL PANEL

F

2

BURNER

G

1

CARRYOVER TUBE

H

1

ELECTRODE

I

2

SIDE SHELF

J

2

SHELF BRACKET, RF/LB

K

2

SHELF BRACKET, RB/LF

L

2

WHEEL

M

1

AXLE ROD

N

1

MATCH HOLDER

O

1

CART LEG, UPPER LEFT ASSEMBLY

P

1

CART LEG, UPPER RIGHT ASSEMBLY

Q

1

CART LEG, LOWER FRONT RIGHT

R

1

CART LEG, LOWER FRONT LEFT

S

1

CART LEG, LOWER REAR ASSEMBLY

T

4

LEG CONNECTER

U

1

EXTENDER

V

2

SIDE BRACE

W

1

FRONT PANEL

X

1

HANDLE

Y

1

TANK SUPPORT BRACKET

Z

2

HEAT TENT

AA

1

COOKING GRATE

BB

1

SWINGAWAY

CC

1

TANK EXCLUSION WIRE

DD

2

KNOB

EE

1

IGNITOR

FF

2

LOWER HINGE

GG

2

UPPER HINGE

HH

1

TANK RETAINER WIRE

II

1

GREASE CUP

JJ

1

GREASE CUP CLIP

NOT Pictured

…

1

HARDWARE PACK

…

1

ASSY INSTRUCTION, ENGLISH

…

1

ASSY INSTRUCTION, FRENCH
