1. DO NOT energize the room heating unit while disassembled or
without all ceramic heat storage bricks in place.
2. DO NOT store or use materials that may produce explosive or
flammable gases near the room heating unit.
3. Maintain the placement and clearance requirements specified in this
manual. (Pages 2.02)
4. DO NOT allow objects to fall between the room heating unit and
the wall.
5. DO NOT place anything on top of the room heating unit.
6. DO NOT stick any objects through the air discharge grill.
7. Disconnect power to all circuits before servicing. This room heating
unit may be connected to more than one branch circuit.
8. Installation of and/or service to this heater should be performed by
a qualified technician in accordance with information contained
herein and with national, state, and local codes and requirements.
9. A repeated message display of “CORE FAIL” on the heater’s
control panel indicates a need for service by a qualified technician.
Safety Precautions
2100 Series Safety Information
Built-in Safety Devices
DEVICE NAME FUNCTION
These limits monitor temperature along the back and top panels of
the heater and the brick core. If normal operating temperature is
exceeded, one or both of these switches will interrupt power to the
heating elements and the heater's control panel will display "CORE
FAIL". If the "CORE FAIL" message occurs repeatedly, verify
heater clearances have not been violated and that objects have not
fallen between the heater and the wall. If clearances are correct,
contact a service technician.
Monitors discharge air temperature and interrupts power to the
control circuit if normal operating temperature is exceeded. This
limit switch helps protect against the heating of objects which may
obstruct the air discharge area or violate grill clearances. If normal
operating temperature is exceeded, this switch will open . When
this switch opens, the discharge air system is disabled and the
heater’s control panel display will no longer illuminate. To reset
the system, press the manual reset button on the limit switch. If the
switch opens repeatedly, verify that grill clearances are not vio-
lated. If correct, contact a service technician.
If the heater is not in the upright position, this switch interrupts
power to the heating elements and the blower. This prevents the
heater from storing heat in or discharging heat from the brick core.
lOCATION
ON hEATEr
Inside the Back Panel
(Extends across the
length of the heater)
Inside the
Air Discharge
Compartment (Grill Area)
Inside the Electrical
Compartment
(Mounted on the Back Panel
to the Left of the Relay Board)
Core Charging High
Limit Switch
(Manual Reset)
Discharge Air High
Limit Switch
(Manual Reset)
Tip Over Switch
(Heaters equipped with a
security base only.)
(Auto Reset)
WARNING
Hazardous Voltage: Risk of
electric shock. Can cause injury
or death. This heater may be
connected to more than one
branch circuit. Disconnect power
to all circuits before installing or
servicing. Installation of and/or
service to this equipment MUST
be performed by a qualified
technician.
Risk of fire. Can cause injury or
death. Violation of the clearance
requirements can cause improper
operation of the equipment.
Maintain the placement and
clearance requirements specified.
Clearance Violation
High Limit Switch
(Manual Reset)
Inside the Top Panel (Ex-
tends across front edge)
Power Indicator Light
Lower Right Corner
(2100 Series Plug-In
Heaters Only)
The power indicator light indicates that power is being applied to
the heater. Disconnect power to all circuits before installing and/or
servicing this equipment.
